Sullivan Palatek D1600 Diesel Compressor
The Sullivan Palatek D1600 Diesel Compressor delivers powerful performance with 1600 CFM at 150 psig, driven by a 535 HP Cummins Tier 4 Final engine. Built for demanding industrial environments, it features a rugged galvanneal enclosure, steel TC-certified fuel tank, dual axle running gear, and a solar-powered battery charger. Its advanced SPEC electronic controller offers real-time diagnostics, multilingual readouts, and automatic shutdown protection. Designed for both performance and reliability, it includes a twin screw air end, noise-limited operation at 76 dBA, and a full containment base, making it ideal for heavy-duty applications in extreme environments.
Equipment Specifications
- Model: D1600PH1CU4
- Rated Delivery: 1600 CFM (45 m³/min)
- Rated Operating Pressure: 150 psig (10.4 bar)
- Operating Pressure Range: 90–170 psig (6.2–11.3 bar)
- Engine: Cummins QSX 15 Tier 4 Final
- Power Rating: 535 HP @ 2100 RPM
- Idle Speed: 1400 RPM
- Fuel Tank Capacity: 224 gal (848 L)
- DEF Volume: 15 gal (56.7 L)
- Weight (Serviced): 19,500 lbs
- Dimensions (L × W × H): 254.31″ × 90.15″ × 111.82″
- Air End: 321mm Twin Screw Direct Drive
- Service Connection: 3”
- Noise Level: 76 dBA @ 7 meters
- Running Gear: Dual axle with electric brakes
- Chassis: Four-point lifting bail, adjustable 3″ lunette eye
- Material: Galvanneal sheet metal enclosure
- Battery: Solar charger equipped
Safety and Usage Guidelines
- Always inspect oil, coolant, and fuel levels before operation
- Operate within ambient temperature range of -40°F to +125°F (-40°C to +52°C)
- Use appropriate PPE when near air discharge or during maintenance
- Ensure unit is grounded and securely hitched when towing
- Do not exceed the recommended pressure or RPM ratings
- Keep all service doors closed during operation
- Shutdown the compressor immediately if low fuel or critical alarms are displayed
- Utilize the SPEC digital controller for safe monitoring and diagnostics
- Follow all manufacturer service intervals and guidelines
