Sullivan Palatek D1150 Compressor
The Sullivan Palatek D1150PXHD1CU4 Diesel Compressor is a high-capacity, dual-pressure machine engineered for extreme-duty applications. Delivering 1150 CFM at 350 PSI or 900 CFM at 500 PSI, it’s powered by a robust 535 HP Cummins QSX 15 Tier 4 Final engine. This two-stage rotary screw unit features a durable 224-gallon steel fuel tank, electric brakes, containment base, and dual-axle running gear for safe transport. Its advanced SPEC digital controller provides multilingual diagnostics, temperature and pressure monitoring, and real-time alerts. With optional aftercoolers and instrument-grade filtration, the D1150 is built for clean, efficient, and powerful performance.
Equipment Specifications
- Model: Sullivan-Palatek D1150PXHD1CU4
- Compressor Type: Two-stage, oil-flooded rotary screw
- Air End: 20/12 Two Stage, manufactured by Sullivan-Palatek
- Rated Delivery: 1150 CFM @ 350 psi (32.6 m³/min @ 24.2 bar), 900 CFM @ 500 psi (25.5 m³/min @ 34.5 bar)
- Operating Pressure Range: 270–500 psi (18.6–34.5 bar)
- Service Connections: Dual air outlets with 3″ NPT
- Fuel Tank Capacity: 224 gal (848 L)
- Engine: Cummins QSX 15 Tier 4 Final
- Horsepower: 535 HP (399 kW) @ 1900 RPM
- Idle Speed: 1400 RPM
- DEF Volume: 15 gal (56.7 L)
- Estimated Weight (Serviced): 19,500 lbs
- Dimensions (L x W x H): 254.31″ x 90.15″ x 111.82″
Safety and Usage Guidelines
- Ensure proper ventilation and stable surface placement during operation
- Use appropriate PPE, including hearing and eye protection
- Monitor digital readouts for compressor temperature, pressure, and fuel levels
- Allow engine to cool before refueling; do not service while running
- Use only certified parts and filters for maintenance and replacements
- Follow all shutdown and startup procedures as outlined in the user manual
- Utilize the containment base to prevent environmental hazards
- Drain fluids using designated points—do not crawl under the unit
