Genie® GTH™-5519 Telehandler
The Genie® GTH™-5519 Telehandler is a compact, versatile lifting solution built for performance and maneuverability on tight job sites.
With a maximum lift height of 18 ft 10 in, forward reach of 11 ft 3 in, and a lifting capacity of up to 5,500 lbs, it delivers
reliable productivity in material handling applications. Powered by a durable Deutz TCD 2.9 diesel engine, the GTH-5519 combines
strength with efficiency, offering 4-wheel steering, excellent turning radius, and smooth hydraulic performance. Compact dimensions
allow easy transport and access through confined spaces, making it ideal for construction, agriculture, and industrial operations.
Equipment Specifications
- Engine: Deutz TCD 2.9 diesel, 12V system, 95-amp alternator
- Horsepower: N/A (Deutz TCD 2.9 rated power)
- Operating Weight: 10,360 lb (4,700 kg)
- Maximum Lift Capacity: 5,500 lb (2,495 kg)
- Lift Capacity at Max Height: 4,400 lb (1,996 kg)
- Lift Capacity at Max Reach: 1,900 lb (862 kg)
- Maximum Lift Height: 18 ft 10 in (5.74 m)
- Maximum Forward Reach: 11 ft 3 in (3.43 m)
- Reach at Max Height: 1 ft 10 in (0.56 m)
- Drive Speed: 15 mph (24 km/h)
- Turning Radius (4WS): 11 ft (3.35 m)
- Hydraulic Flow: 17 gpm (64 lpm) @ 3,918 psi (270 bar)
- Fuel Tank Capacity: 15.8 gal (59.8 L)
- Hydraulic System Capacity: 31.7 gal (120 L)
- Tires: 12 × 16.5 in, 10 ply
- Dimensions: Length 12 ft 3 in (3.73 m), Width 5 ft 11 in (1.80 m), Height 6 ft 6 in (1.98 m), Wheelbase 7 ft 6 in (2.29 m)
Safety & Usage Guidelines
- Perform daily checks of hydraulics, tires, and load-handling components.
- Do not exceed rated lift capacities at height or reach.
- Always secure loads properly before lifting or extending boom.
- Maintain safe travel speeds on uneven or rough terrain.
- Engage parking brake when stationary and use stabilizers if required.
- Operate only on stable surfaces and avoid side slopes.
- Ensure clear communication with ground personnel during lifts.
- Follow all OSHA and site-specific telehandler safety regulations.
