Doosan XHP1170 Diesel Compressor
The Sullivan Palatek XHP1170 is a high-performance diesel-powered rotary screw compressor delivering up to 1170 cfm at 365 psig. Designed for heavy-duty applications, it features a Cummins QSX15 Tier 4 Final engine, rugged chassis, and high-capacity fuel and DEF tanks for long runtime. Ideal for remote worksites and high-altitude environments, it offers reliable performance, easy maintenance access, and user-friendly controls. With superior airflow, safety-focused design, and robust construction, the XHP1170 is built to power demanding pneumatic equipment and keep operations running efficiently even under the toughest jobsite conditions.
Equipment Specifications
- Compressor: Rotary Screw
- Free-Air Delivery: 1170 cfm (33.1 m³/min)
- Rated Operating Pressure: 365 psig (25.1 bar)
- Pressure Range: 140–365 psig (9.7–25.2 bar)
- Air Discharge Outlet: 3 in (76.2 mm), Qty: 1 (2 with IQ)
- Compressor Oil Capacity: 55 gal (208 L)
- Fuel Tank Capacity: 222.4 gal (841.9 L)
- DEF Tank Capacity: 15.6 gal (59 L)
- Engine: Cummins QSX15, 6-cylinder, Tier 4 Final
- Displacement: 912 cu in (14.9 L)
- Rated Speed: 1800 rpm
- Idle Speed: 1200 rpm
- BHP @ Rated Speed: 580 (433 kW)
- Electrical: 24 volts
- Fuel Consumption @ 100% Load: 23.5 gph (89 L/h)
- Engine Oil Capacity: 48 qt (45 L)
- Radiator Coolant Capacity: 26 gal (98 L)
- Altitude Capability: 9800 ft (2987 m)
- Dimensions with Running Gear (L×W×H): 292.4 × 90.1 × 99.5 in (7427 × 2289 × 2527 mm)
- Shipping Weight (w/o fuel): 17,355 lb (7871 kg)
- Working Weight (with fuel): 18,835 lb (8542 kg)
- Dimensions without Running Gear (L×W×H): 228.2 × 90.1 × 98.2 in (5796 × 2289 × 2494 mm)
- Shipping Weight (w/o fuel): 16,169 lb (7333 kg)
- Working Weight (with fuel): 17,860 lb (8100 kg)
Safety and Usage Guidelines
- Always operate on a level surface to prevent tipping or shifting
- Wear appropriate PPE, including ear protection, when operating
- Ensure proper ventilation when used in enclosed or semi-enclosed areas
- Perform daily pre-start inspections and monitor fluid levels
- Keep clear of rotating components and high-pressure air discharge areas
- Do not exceed rated pressure limits or modify factory settings
- Shut down and depressurize unit before performing any maintenance
- Ensure compliance with all local and federal safety regulations
